Panorama 7Stars Aluminium Minimalist Sliding Systems

Through Panorama 7Stars by QFORT we offer you an aluminium sliding door system with an elegant, minimalist design and high performance over time.

Panorama 7Stars provide a large glazed surface, with a high visibility on the outside environment, as well as an increased brightness of the room, allowing the penetration of a large amount of natural light, also having an increased watertight due to the latest technical specifications.

Leave us your details, and we’ll contact you as soon as possible

Ask for a quote
- or book a video chat with one of our consultants:
VIRTUAL SHOWROOM
Advice
Advice on choosing the best products

Advantages Panorama 7Stars Aluminium Sliding Systems

  • Panorama by QFORT sliding systems are characterised by a stylish, minimalist design, being dedicated to the exclusive style lovers.
  • The narrow profiles and the possibility of burying them into walls and floors help to save a considerable amount of space in the house.
  • The large glazed area of the Panorama by QFORT aluminium sliding systems provides high visibility of the outdoor environment, as well as a high light level, allowing penetration of large amounts of natural light.
  • Representing the definition of modern, elegant and minimalist style, the Panorama by QFORT sliding systems include state-of-the-art technological systems that are easy to handle and use. Thus, you can opt for manual or electric control.
  • The Panorama by QFORT sliding systems are suitable for any type of space and are available in various construction options with 1, 2, 3, 4 or 6 moveable sashes offering the possibility of joining two 90° sliders when the available space requires it.
  • OPTIONAL: The Panorama by QFORT aluminium sliding systems can be equipped with a drain specially designed to eliminate the risk of water infiltration, thus increasing the overall comfort of your home.Rigolă de preluare a apei

Customisation of Panorama 7Stars Aluminium Sliding Systems



Glass of Panorama by QFORT Aluminium Sliding Systems

The aluminium sliding systems in the Panorama by QFORT range are equipped with the highest-quality insulating glass. As standard, they have LowE glass in a 54 mm thick package, which gives superior heat-insulation properties.

In addition, the glass package thickness, as well as the other components and technical specifications of the Panorama by QFORT sliding systems, give these products superior noise-insulation properties, resulting in increased overall comfort of your home.

Find out more about insulated glazing!

Find out more

Heat insulation of Panorama by QFORT Sliding Systems

High-quality insulating glass, the aluminium profiles and state-of-the-art technical specifications contained in the Panorama by QFORT sliding systems give them superior heat-insulation properties, helping to achieve energy efficiency and increase the overall comfort of your home.

The heat-insulation coefficient of Panorama by QFORT sliding systems is Uw ≥ 0.9 W/m²K* and may vary depending on the type of the sliding doors chosen, dimensions and glass.

*The Uw value was calculated for a construction of length, L = 3600 mm and height, H = 4000 mm with two wings and 54 mm glazing (LowE glass). The heat-insulation coefficient at the level of the insulating glass is Ug ≥ 0.5.

Noise insulation of Panorama by QFORT Sliding Systems

The thickness of the 54 mm insulated glazing package, as well as the aluminium profiles advanced technical features that provide increased sealing to Panorama by QFORT sliding systems result in better noise-insulation properties and thus increased overall comfort of your home.

The noise-insulation coefficient of the sliding systems in the Panorama by QFORT range can reach up to 43 dB and may vary depending on the type of insulating glass chosen or the size of the sliding system.

Available colours for Panorama 7Stars Aluminium Sliding Systems

The Panorama by QFORT sliding profiles are available in multiple colour variants. The RAL colours are delivered with structural finish, as standard.

Group 1 – standard colours

Available colours for PVC Windows Aluminium Lining

RAL 9016 (PE9016TD)

Available colours for PVC Windows Aluminium Lining

RAL 9010 (PE9010TD)

Available colours for PVC Windows Aluminium Lining

RAL9006 (PE9006TX)

Available colours for PVC Windows Aluminium Lining

RAL 9007 (P9007TX)

Available colours for PVC Windows Aluminium Lining

RAL 7016 (PE7016TD)

Available colours for PVC Windows Aluminium Lining

RAL 9005 (PE9005TD)

Available colours for PVC Windows Aluminium Lining

RAL 8017 (P8017T)

Available colours for PVC Windows Aluminium Lining

RAL 6005 (PE6005TD)

Group 2 – colours on order

Available colours for PVC Windows Aluminium Lining

RAL 1013 (PE1013TD)

Available colours for PVC Windows Aluminium Lining

RAL 1015 (P1015T)

Available colours for PVC Windows Aluminium Lining

RAL 3004 (P3004T)

Available colours for PVC Windows Aluminium Lining

RAL 3005 (P3005T)

Available colours for PVC Windows Aluminium Lining

RAL 5001 (P5001T)

Available colours for PVC Windows Aluminium Lining

RAL 5003 (PE5003TD)

Available colours for PVC Windows Aluminium Lining

RAL 5008 (PE5008TD)

Available colours for PVC Windows Aluminium Lining

RAL 5024 (P5024T)

Available colours for PVC Windows Aluminium Lining

RAL 5010 (P5010T)

Available colours for PVC Windows Aluminium Lining

RAL 6009 (P6009T)

Available colours for PVC Windows Aluminium Lining

RAL 6019 (P6019T)

Available colours for PVC Windows Aluminium Lining

RAL 6021 (P6021T)

Available colours for PVC Windows Aluminium Lining

RAL 7001 (P7001)

Available colours for PVC Windows Aluminium Lining

RAL 7012 (PE7012TD)

Available colours for PVC Windows Aluminium Lining

RAL 7022 (TX7022DE)

Available colours for PVC Windows Aluminium Lining

RAL 7035 (P7035T)

Available colours for PVC Windows Aluminium Lining

RAL 7039 (P7039T)

Available colours for PVC Windows Aluminium Lining

RAL 8014 (PE8014TD)

Available colours for PVC Windows Aluminium Lining

RAL 9001 (P9001T)

Group 2 – decorative finishes (non-RAL)

Available colours for PVC Windows Aluminium Lining

Black blasted - 2100

Available colours for PVC Windows Aluminium Lining

Blasted green - 2500

Available colours for PVC Windows Aluminium Lining

Blasted gray - 2900

Available colours for PVC Windows Aluminium Lining

2525 MARS

Available colours for PVC Windows Aluminium Lining

PUNTO GRIGIO

Available colours for PVC Windows Aluminium Lining

GRIGIO ANTICO

Available colours for PVC Windows Aluminium Lining

DB703

Technical details of Panorama 7Stars Aluminium Sliding Systems

Features of Panorama by QFORT Panorama 7Stars Aluminium Sliding Systems

The Panorama 7Stars by QFORT sliding systems have the following features:

  • Central interlock size (meeting point of the sash): 25mm;
  • Assembly depth: two-rail frame – 180mm; three-rail frame – 278mm;
  • Exterior wall thickness of profiles: sash 2mm, frame 1.5mm;
  • Thermal insulation coefficient Uw ≥ 0.98 W/m²K*;
  • Elegant and minimalist design;
  • Large glazing;
  • Weatherproof;
  • Increased security;
  • There is the possibility of constructions with electrical wings;
  • There is the possibility of pocket-sliding system.

System indicated for sashes with a maximum width of 3000 mm and a maximum height of 3600 mm.

Types of opening of Panorama 7Stars Aluminium Sliding Systems

The Panorama by QFORT sliding systems can be operated either manually or electrically via two- or four-channel remote controls, or via photocell.

For the two-wing type of opening, when both can be opened, it is possible to use an electrical opening sash and a manual opening sash.

Electric control

Sliding systems with 2 wings

2 wings

Sliding systems with 2 wings

2 wings

Sliding systems with 2 wings

2 wings

Manual control

Sliding systems with 2 wings

2 wings

Sliding systems with 2 wings

2 wings

Sliding systems with 2 wings

2 wings

Sliding systems with 3 wings

3 wings

Sliding systems with 4 wings

4 wings

Sliding systems 4 wings

4 wings

Sliding systems with 4 wings – two 90° sliders

4 wings – two 90° sliders

Sliding systems with 4 wings – two 90° sliders

4 wings – two 90° sliders

Sliding systems with 6 wings

6 wings

Sliding systems with 6 wings – two 90° sliders

6 wings – two 90° sliders

Pocket-sliding function of Panorama 7Stars Aluminium Sliding Systems

The pocket-sliding function was designed to allow for the largest possible opening by sliding the sash into the wall.

Galandage - manual operation - 1 sash - opening to the right

Galandage - manual operation - 1 sash - opening to the left

Galandage - manual operation - double-sash - 1 rail - double opening

Galandage - manual operation - double-sash - 2 rails - opening to the right

Galandage - manual operation - double-sash - 2 rails - opening to the left

Galandage - manual operation - triple-sashes - opening to the right

Galandage - manual operation - triple-sashes - opening to the left

Galandage - manual operation - four-sashes - double opening

Contact us!









    Garantie

    *The warranty period may vary depending on the components and specifications of the product. Please refer to the warranty certificate for more details.
