Panorana 7Stars Aluminium Minimalist Sliding Systems
With the Panorama by QFORT range, we provide you with a series of aluminium sliding systems featuring a stylish, minimalist design and high performance over time.
The Panorama by QFORT sliding systems provide increased visibility of the outdoor environment and also have high resistance to bad weather, due to the state-of-the-art technical specifications.
Leave us your details, and we’ll contact you as soon as possible
Ask for a quoteAdvantages Panorana 7Stars Aluminium Sliding Systems
- Panorama by QFORT sliding systems are characterised by a stylish, minimalist design, being dedicated to the exclusive style lovers.
- The narrow profiles and the possibility of burying them into walls and floors help to save a considerable amount of space in the house.
- The large glazed area of the Panorama by QFORT aluminium sliding systems provides high visibility of the outdoor environment, as well as a high light level, allowing penetration of large amounts of natural light.
- Representing the definition of modern, elegant and minimalist style, the Panorama by QFORT sliding systems include state-of-the-art technological systems that are easy to handle and use. Thus, you can opt for manual or electric control.
- The Panorama by QFORT sliding systems are suitable for any type of space and are available in various construction options with 1, 2, 3, 4 or 6 moveable sashes offering the possibility of joining two 90° sliders when the available space requires it.
- OPTIONAL: The Panorama by QFORT aluminium sliding systems can be equipped with a drain specially designed to eliminate the risk of water infiltration, thus increasing the overall comfort of your home.
Customisation of Panorana 7Stars Aluminium Sliding Systems
Glass of Panorama by QFORT Aluminium Sliding Systems
The aluminium sliding systems in the Panorama by QFORT range are equipped with the highest-quality insulating glass. As standard, they have LowE glass in a 54 mm thick package, which gives superior heat-insulation properties.
In addition, the glass package thickness, as well as the other components and technical specifications of the Panorama by QFORT sliding systems, give these products superior noise-insulation properties, resulting in increased overall comfort of your home.
Find out more about insulated glazing!
Heat insulation of Panorama by QFORT Sliding Systems
High-quality insulating glass, the aluminium profiles and state-of-the-art technical specifications contained in the Panorama by QFORT sliding systems give them superior heat-insulation properties, helping to achieve energy efficiency and increase the overall comfort of your home.
The heat-insulation coefficient of Panorama by QFORT sliding systems is Uw ≥ 0.9 W/m²K* and may vary depending on the type of the sliding doors chosen, dimensions and glass.
*The Uw value was calculated for a construction of length, L = 3600 mm and height, H = 4000 mm with two wings and 54 mm glazing (LowE glass). The heat-insulation coefficient at the level of the insulating glass is Ug ≥ 0.5.
Noise insulation of Panorama by QFORT Sliding Systems
The thickness of the 54 mm insulated glazing package, as well as the aluminium profiles advanced technical features that provide increased sealing to Panorama by QFORT sliding systems result in better noise-insulation properties and thus increased overall comfort of your home.
The noise-insulation coefficient of the sliding systems in the Panorama by QFORT range can reach up to 43 dB and may vary depending on the type of insulating glass chosen or the size of the sliding system.
Available colours for Panorana 7Stars Aluminium Sliding Systems
The Panorama by QFORT sliding profiles are available in multiple colour variants. The RAL colours are delivered with structural finish, as standard.
Group 1 – standard colours

RAL 9016 (PE9016TD)

RAL 9010 (PE9010TD)

RAL9006 (PE9006TX)

RAL 9007 (P9007TX)

RAL 7016 (PE7016TD)

RAL 9005 (PE9005TD)

RAL 8017 (P8017T)

RAL 6005 (PE6005TD)
Group 2 – colours on order

RAL 1013 (PE1013TD)

RAL 1015 (P1015T)

RAL 3004 (P3004T)

RAL 3005 (P3005T)

RAL 5001 (P5001T)

RAL 5003 (PE5003TD)

RAL 5008 (PE5008TD)

RAL 5024 (P5024T)

RAL 5010 (P5010T)

RAL 6009 (P6009T)

RAL 6019 (P6019T)

RAL 6021 (P6021T)

RAL 7001 (P7001)

RAL 7012 (PE7012TD)

RAL 7022 (TX7022DE)

RAL 7035 (P7035T)

RAL 7039 (P7039T)

RAL 8014 (PE8014TD)

RAL 9001 (P9001T)
Group 2 – decorative finishes (non-RAL)

Black blasted - 2100

Blasted green - 2500

Blasted gray - 2900

2525 MARS

PUNTO GRIGIO

GRIGIO ANTICO

DB703
Technical details of Panorana 7Stars Aluminium Sliding Systems
Features of Panorama by QFORT Panorana 7Stars Aluminium Sliding Systems
The Panorama by QFORT sliding doors have the following features:
- The Panorama by QFORT sliding systems have a mount depth of 180 mm for a two-rail frame, and 278 mm for three-rail frames.
- The outer wall thickness of the profiles is 2 mm.
- The Panorama by QFORT sliding systems may be built with 1, 2, 3, 4 or 6 moveable sashes, and the possibility of joining two 90° sliders without vertical mullion.
- The Panorama by QFORT sliding systems have narrow aluminium profiles with the possibility of burying the profiles into walls and floors.
- The maximum weight for the sash of the Panorama by QFORT sliding systems is 400 kg.

Types of opening of Panorana 7Stars Aluminium Sliding Systems
The Panorama by QFORT sliding systems can be operated either manually or electrically via two- or four-channel remote controls, or via photocell.
For the two-wing type of opening, when both can be opened, it is possible to use an electrical opening sash and a manual opening sash.
Electric control

2 wings

2 wings

2 wings
Manual control

2 wings

2 wings

2 wings

3 wings

4 wings

4 wings

4 wings – two 90° sliders

4 wings – two 90° sliders

6 wings

6 wings – two 90° sliders
Contact us!
*The warranty period may vary depending on the components and specifications of the product. Please refer to the warranty certificate for more details.
